Fisher® HD2™ Snowplow

Keep Raising the Bar

This blade comes in four different sizes, so no matter what you're driving there's an HD2™ snowplow that'll work for you. It's also strong—10 vertical ribs strong—which means even the toughest storms can't stop you. Combined with reliable and fast hydraulics, this plow moves a lot of snow and also raises the bar.

*Main plow image shown with accessories

TYPE OF SNOWPLOW
Straight Blade Snowplow

UNIQUE FEATURES


Plow Blade Construction		Structural Reinforcement
Featuring a rugged, 29" tall, powder coated, steel blade, the HD2™ snow plow is available in 7' 6", 8', 8' 6" and 9' widths, ensuring you can find the right blade for your vehicle. A standard high-carbon steel cutting edge provides increased wear resistance.		The rugged HD2™ snow plow blade is reinforced with 10 vertical ribs welded into a rigid framework, which provides additional structural support and torsional strength, even under heavy load.


Reliable Hydraulics		Trip Protection
We produce our own hydraulic system to ensure the highest standards of performance, quality and reliability, giving you a plow that is fast, responsive and built to last. All critical hydraulic components are fully enclosed for protection from the elements.		Our industry-leading trip-edge design protects you and your equipment when encountering hidden obstacles. For improved efficiency and less cleanup, only the bottom edge trips, keeping the blade upright and plowed snow in front of the blade. The FISHER® trip edge uses compression-type springs that never require adjustment and will not wear out like extension springs.


HD2™ for Skid-Steers
The FISHER® HD2™ snowplow is also available with skid-steer mounting options. Contact a Hitch City near you to find out pricing, customization and applications of a skid-steer HD2™ snowplow.

UNIVERSAL FEATURES

Contact a Hitch City near you to find out how to outfit your Fisher® HD2™ Snowplow


INTENSIFIRE™ Headlamps		Minute Mount® 2 Snowplow Mounting System
Available in both LED and Dual-Halogen models, INTENSIFIRE™ headlamps are engineered and tested for maximum light output, performance and durability to keep you ahead of the next storm.		The reliable, mechanical attachment design of the Minute Mount® 2 snowplow mounting system allows for easy hook-up with no tools required and no electrical switches to fail and leave you struggling out in the cold.


Chain Lift Design		FLEET FLEX Electrical System
The FISHER® chain lift design offers a wide range of performance and reliability advantages over a direct lift system.		With the FISHER® FLEET FLEX Electrical System, you have true fleet interchangeability. Unlike other manufacturers who require a different control system for different plows, the FISHER FLEET FLEX system lets you operate any FISHER Minute Mount® 2 plow on any truck with the same Fish-Stik^® hand-held or joystick control.


SECURITY GUARD™ Anti-Theft System		Universal Control Options
The exclusive SECURITY GUARD™ anti-theft system is a safe and secure way to electronically lock your snow plow whenever it is detached from your truck.		Choose between the ergonomic Fish-Stik^® hand-held control or the dash-mounted joystick control based on your preference. Both feature automatic shutoff, backlit buttons for night operation, and LED lights which indicate "power" and "float" mode. Additional features include programmable "soft-stop," "one-touch" float, built-in SECURITY GUARD™ Anti-Theft System, and plug-in connector for easy removal.


STORM GUARD™ Baked-On Powder Coat		Isolation Module
The industry’s best protection against wear and rust, the STORM GUARD™ baked-on powder coat with epoxy primer is standard on all FISHER® snow plows.		An underhood module transfers lights from vehicle to plow automatically and improves system reliability by using plug 'n play, sealed electrical connections that comply with OEM requirements. Isolating the plow's electrical system from the vehicle's prevents the potential of electrical system damage in the event of a shorted circuit.


Pre-Punched Blades for Accessories
The blade is pre-punched for easy installation of accessories, providing a custom fit. The pre-punched holes also prevent damage to the powder coat that can sometimes occur when installing an accessory.

PRODUCT SPECIFICATIONS


	If you have questions about which FISHER® HD2™ Snowplow is best for you, please call or contact us and we will be happy to assist you.		Download Snowplow Full-line Product Brochure

FISHER® HD2™ SNOWPLOW
Models	7' 6	8'	8' 6	9'
Blade Width	7' 6"	8'	8' 6"	9'
Blade Height	29"	29"	29"	29"
Blade Gauge	12	12	12	12
Trip Springs	3	4	4	4
Vertical Ribs	10	10	10	10
Lift Cylinder	1 ½" x 10"	1 ½" x 10"	1 ½" x 10"	1 ½" x 10"
Angling Rams	1 ½" x 12"	1 ½" x 12"	1 ½" x 12"	1 ½" x 12"
Plowing Width (Full Angle)	6' 9"	7' 2"	7' 7"	8' 1"
Approx. Weight*	684 lb	734 lb	750 lb	770 lb
Disc Shoes	Cast Iron	Cast Iron	Cast Iron	Cast Iron
Cutting Edge	⅜" x 6" Steel	½" x 6" Steel	½" x 6" Steel	½" x 6" Steel
Mount Type	Minute Mount® 2	Minute Mount® 2	Minute Mount® 2	Minute Mount® 2
*Does not include vehicle mount. Please contact a Hitch City associate for specific vehicle application details.
