SD Series









Day or Night, the Worst Only Brings Out Your Best



Winter won't let up and with the help of the FISHER® SD Series snowplow, neither will you. The FISHER SD Series snowplows are rugged, hard-working plows built for lighter four-wheel-drive vehicles so you don't have to upgrade your truck to get a high-performance snowplowing machine.


TYPE OF SNOWPLOW
Straight Blade Snowplow


FISHER® SD SERIES snowplow











UNIQUE FEATURES








Fisher® SD Series - PLOW BLADE CONSTRUCTION



Fisher® SD Series - STRUCTURAL REINFORCEMENT


Plow Blade Construction



Structural Reinforcement


The 26" tall, powder coated, steel blade is available in 6' 9" and 7' 6" widths, and features a poly cutting edge with an aggressive, 75-degree attack angle for enhanced scraping and back dragging.     The SD Series snow plow has eight vertical ribs and a torsion tube ensuring you have the durability you need when the going gets tough.


Fisher® SD Series - RELIABLE HYDRAULICS



Fisher® SD Series - TRIP PROTECTION


Reliable Hydraulics



Trip Protection


We produce our own hydraulic system to ensure the highest standards of performance, quality and reliability, giving you a plow that is fast, responsive and built to last.

All critical hydraulic components are fully enclosed for protection from the elements.
    Our industry-leading trip-edge design protects you and your equipment when encountering hidden obstacles. For improved efficiency and less cleanup, only the bottom edge trips, keeping the blade upright and plowed snow in front of the blade.

The FISHER® trip edge uses compression-type springs that never require adjustment and will not wear out like extension springs.










UNIVERSAL FEATURES








Contact a Hitch City near you to find out how to outfit your Fisher® SD Series Snowplow



Fisher® SD Series - INTENSIFIRE™ Headlamps



Fisher® SD Series - MINUTE MOUNT® 2 SNOWPLOW MOUNTING SYSTEM


INTENSIFIRE™ Headlamps



Minute Mount® 2 Snowplow Mounting System


Available in both LED and Dual-Halogen models, INTENSIFIRE™ headlamps are engineered and tested for maximum light output, performance and durability to keep you ahead of the next storm.     The reliable, mechanical attachment design of the Minute Mount® 2 snowplow mounting system allows for easy hook-up with no tools required and no electrical switches to fail and leave you struggling out in the cold.


Fisher® SD Series - CHAIN LIFT DESIGN



Fisher® SD Series - FLEET FLEX Electrical System


Chain Lift Design



FLEET FLEX Electrical System


The FISHER® chain lift design offers a wide range of performance and reliability advantages over a direct lift system.     With the FISHER® FLEET FLEX Electrical System, you have true fleet interchangeability. Unlike other manufacturers who require a different control system for different plows, the FISHER FLEET FLEX system lets you operate any FISHER Minute Mount® 2 plow on any truck with the same Fish-Stik® hand-held or joystick control.


Fisher® SD Series - SECURITY GUARD™ ANTI-THEFT SYSTEM



Fisher® SD Series - UNIVERSAL CONTROL OPTIONS


SECURITY GUARD™ Anti-Theft System



Universal Control Options


The exclusive SECURITY GUARD™ anti-theft system is a safe and secure way to electronically lock your snow plow whenever it is detached from your truck.     Choose between the ergonomic Fish-Stik® hand-held control or the dash-mounted joystick control based on your preference. Both feature automatic shutoff, backlit buttons for night operation, and LED lights which indicate "power" and "float" mode.

Additional features include programmable "soft-stop," "one-touch" float, built-in SECURITY GUARD™ Anti-Theft System, and plug-in connector for easy removal.


Fisher® SD Series - STORM GUARD™ Baked-On Powder Coat



Fisher® SD Series - ISOLATION MODULE


STORM GUARD™ Baked-On Powder Coat



Isolation Module


The industry’s best protection against wear and rust, the STORM GUARD™ baked-on powder coat with epoxy primer is standard on all FISHER® snow plows.     An underhood module transfers lights from vehicle to plow automatically and improves system reliability by using plug 'n play, sealed electrical connections that comply with OEM requirements. Isolating the plow's electrical system from the vehicle's prevents the potential of electrical system damage in the event of a shorted circuit.




PRODUCT SPECIFICATIONS






If you have questions about which FISHER® SD SERIES Half-Ton Snowplow is best for you, please call or contact us and we will be happy to assist you.


Download
Snowplow Full-line Product Brochure
  Fisher Snowplow Full-Line Brochure




FISHER® SD SERIES HALF-TON SNOWPLOW
Models   6' 9"   7' 6"
Blade Width   6' 9"   7' 6"
Blade Height   26"   26"
Blade Gauge   14   14
Trip Springs   2   2
Vertical Ribs   8   8
Lift Cylinder   1 ½" x 6"   1 ½" x 6"
Angling Rams   1 ½" x 10"   1 ½" x 10"
Plowing Width (Full Angle)   6' 1"   6' 9"
Approx. Weight*   472 lb   487 lb
Cutting Edge   1" x 6" Poly   1" x 6" Poly
⅜" x 6" Steel**
Mount Type   Minute Mount® 2   Minute Mount® 2
*Does not include vehicle mount. Please contact a Hitch City associate for specific vehicle application details.
**Optional accessory
