XtremeV






Operate at a Higher Level



With the ability to position the plow in V, straight or scoop mode, plowing snow with the XtremeV™ v-plow takes you to the next level. Whether busting through a long driveway or clearing a parking lot full of cars, the XtremeV v-plow makes quick work of brutal winter conditions.


TYPE OF SNOWPLOW
V-Plow


FISHER® XTREMEV™ snowplow











UNIQUE FEATURES








Fisher® XTREMEV™ - PLOW BLADE CONSTRUCTION



Fisher® XTREMEV™ - STRUCTURAL REINFORCEMENT


Plow Blade Construction



Structural Reinforcement


Available in stainless steel or powder coated steel, the XtremeV™ snow plow blade is available in 7' 6", 8' 6" and 9' 6" widths*. The blade comes standard with a high-carbon steel cutting edge, increasing wear resistance, and features a 70-degree attack angle for enhanced scraping and back dragging.

*The 7' 6" model is available in stainless steel only.
    The XtremeV™ v-plow features our rugged x-bracing design which is constructed from four vertical ribs and eight x-bracing ribs. The ribs reinforce the blade for structural integrity and exceptional torsional strength, even under the punishing stress of commercial plowing.


Fisher® XtremeV™ - RELIABLE HYDRAULICS



Fisher® XtremeV™ - TRIP PROTECTION


Reliable Hydraulics



Trip Protection


We produce our own hydraulic system to ensure the highest standards of performance, quality and reliability, giving you a plow that is fast, responsive and built to last.

All critical hydraulic components are fully enclosed for protection from the elements.
    Each v-plow blade features independent trip-edge protection to get over bumps and hidden obstacles, whether in V, scoop, or straight-blade configuration, helping to protect the plow, the truck and the operator. Since only the bottom edge trips, snow stays in front of the blade, so you can keep on going without dumping the entire load of snow.

The FISHER® trip edge uses compression-type springs that never require adjustment and will not wear out like extension springs.


Fisher® XtremeV™ - DOUBLE-ACTING CYLINDERS



Fisher® XtremeV™ - CENTER SNOW CONTROL


Double-Acting Cylinders



Center Snow Control


InstaLock double-acting cylinders allow the operator to lock the wings together to use the v-plow in straight blade mode with single button control. Double-acting cylinders also hold the wings firmly in place for clean, efficient back dragging.     For exceptional snow containment in all positions, the XtremeV™ v-plow has a center deflector designed to prevent snow from going over the top of the blade and the formed cutting edges reduce trailing snow.










UNIVERSAL FEATURES








Contact a Hitch City near you to find out how to outfit your Fisher® XTREMEV™ V-Plow



Fisher® XTREMEV™ - INTENSIFIRE™ Headlamps



Fisher® XTREMEV™ - MINUTE MOUNT® 2 SNOWPLOW MOUNTING SYSTEM


INTENSIFIRE™ Headlamps



Minute Mount® 2 Snowplow Mounting System


Available in both LED and Dual-Halogen models, INTENSIFIRE™ headlamps are engineered and tested for maximum light output, performance and durability to keep you ahead of the next storm.     The reliable, mechanical attachment design of the Minute Mount® 2 snowplow mounting system allows for easy hook-up with no tools required and no electrical switches to fail and leave you struggling out in the cold.


Fisher® XTREMEV™ - CHAIN LIFT DESIGN



Fisher® XTREMEV™ - FLEET FLEX Electrical System


Chain Lift Design



FLEET FLEX Electrical System


The FISHER® chain lift design offers a wide range of performance and reliability advantages over a direct lift system.     With the FISHER® FLEET FLEX Electrical System, you have true fleet interchangeability. Unlike other manufacturers who require a different control system for different plows, the FISHER FLEET FLEX system lets you operate any FISHER Minute Mount® 2 plow on any truck with the same Fish-Stik® hand-held or joystick control.


Fisher® XTREMEV™ - SECURITY GUARD™ ANTI-THEFT SYSTEM



Fisher® XTREMEV™ - UNIVERSAL CONTROL OPTIONS


SECURITY GUARD™ Anti-Theft System



Universal Control Options


The exclusive SECURITY GUARD™ anti-theft system is a safe and secure way to electronically lock your snow plow whenever it is detached from your truck.     Choose between the ergonomic Fish-Stik® hand-held control or the dash-mounted joystick control based on your preference. Both feature automatic shutoff, backlit buttons for night operation, and LED lights which indicate "power" and "float" mode.

Additional features include programmable "soft-stop," "one-touch" float, built-in SECURITY GUARD™ Anti-Theft System, and plug-in connector for easy removal.


Fisher® XTREMEV™ - STORM GUARD™ Baked-On Powder Coat



Fisher® XTREMEV™ - ISOLATION MODULE


STORM GUARD™ Baked-On Powder Coat



Isolation Module


The industry’s best protection against wear and rust, the STORM GUARD™ baked-on powder coat with epoxy primer is standard on all FISHER® snow plows.     An underhood module transfers lights from vehicle to plow automatically and improves system reliability by using plug 'n play, sealed electrical connections that comply with OEM requirements. Isolating the plow's electrical system from the vehicle's prevents the potential of electrical system damage in the event of a shorted circuit.


Fisher® XTREMEV™ - PRE-PUNCHED BLADES FOR ACCESSORIES



Pre-Punched Blades for Accessories



The blade is pre-punched for easy installation of accessories, providing a custom fit. The pre-punched holes also prevent damage to the powder coat that can sometimes occur when installing an accessory.




PRODUCT SPECIFICATIONS






If you have questions about which FISHER® XTREMEV™ V-Plow is best for you, please call or contact us and we will be happy to assist you.


Download
Snowplow Full-line Product Brochure
  Fisher Snowplow Full-Line Brochure




FISHER® XTREMEV™ V-PLOW
Models   7' 6" SS   8' 6" PC or SS   9' 6" PC or SS
Blade Width   7' 6"   8' 6"   9' 6"
Blade Height   29" at Center
30 ¾" at End
  29" at Center
31" at End
  31" at Center
33" at End
Blade Gauge   14   14   14
Trip Springs   4   4   4
Vertical Ribs   12   12   12
Lift Cylinder   1 ½" x 10"   1 ½" x 10"   1 ½" x 10"
Angling Rams   1 ¾" x 11"   1 ¾" x 11"   1 ¾" x 11"
Plowing Width   6' 6" Full Angle
6' 3" Scoop
6' 9" Full V
  7' 5" Full Angle
7' 1" Scoop
7' 7" Full V
  8' 3" Full Angle
7' 11" Scoop
8' 7" Full V
Approx. Weight*   821 lb   899 lb   1,013 lb
Cutting Edge   ⅜" x 6"
½" x 6"**
  ⅜" x 6"
½" x 6"**
  ½" x 6"
Mount Type   Minute Mount® 2   Minute Mount® 2   Minute Mount® 2
PC = Powder Coated Steel
SS = Stainless Steel
*Does not include vehicle mount. Please contact a Hitch City associate for specific vehicle application details.
**Optional accessory
